OEM 5.5 Spinal Pedicle Screw Instrument Set Factories, Pricelist
Product Description
Surgical Instrumentation System
Zipper 5.5 Instrument Set
| No. | English Name | Product Code | Specification | Quantity |
|---|---|---|---|---|
| 1 | Ratchet Handle | 11030001 | — | 1 |
| 2 | Compression Forceps | 11030003 | — | 1 |
| 3 | Spreader Forceps | 11030004 | — | 1 |
| 4 | Dual Action Rod Gripper | 11030007 | — | 2 |
| 5 | Forceps Rocker | 11030008 | — | 1 |
| 6 | Rod Bender | 11030009 | — | 1 |
| 7 | Counter Torque | 11030010 | — | 1 |
| 8 | Straight Probe | 11030012 | Ф2.7 | 1 |
| 9 | Curved Probe | 11030013 | Ф2.7 | 1 |
| 10 | Awl | 11030014 | — | 1 |
| 11 | In-Situ Rod Bender | 11030015 | Left | 1 |
| 12 | In-Situ Rod Bender | 11030016 | Right | 1 |
| 13 | Tap | 11030035 | Ф4.5 | 1 |
| 14 | Tap | 11030018 | Ф5.5 | 1 |
| 15 | Tap | 11030017 | Ф6.0 | 1 |
| 16 | Tap | 11030019 | Ф6.5 | 1 |
| 17 | Tab Remover | 11030020 | — | 1 |
| 18 | Dual-Ended Feeler Probe | 11030022 | — | 1 |
| 19 | Rod Rotation Wrench | 11030023 | — | 1 |
| 20 | Marking Pin Inserter | 11030024 | — | 1 |
| 21 | Marking Pin | 11030025-1 | Ball Type | 4 |
| 22 | Marking Pin | 11030025-2 | Column Type | 4 |
| 23 | Breakoff Driver | 11030026 | — | 1 |
| 24 | Rod Pusher | 11030027 | — | 1 |
| 25 | Multi-Angle Screwdriver | 11030028 | — | 2 |
| 26 | Mono-Angle Screwdriver | 11030029 | — | 2 |
| 27 | Rod Trial | 11030030 | 290mm | 1 |
| 28 | Screwdriver Shaft for Crosslink | 11030031 | SW3.5 | 1 |
| 29 | Angled Rod Holder | 11030032 | — | 1 |
| 30 | Set Screw Holder | 11030033 | T27 | 2 |
| 31 | Set Screwdriver | 11030034 | T27 | 2 |
| 32 | Rod Trial | 11030036 | 110mm | 1 |
| 33 | Straight Handle | 11030037 | — | 1 |
| 34 | T-Shape Handle | 11030038 | — | 1 |
| 35 | Measuring Card | 11030039 | — | 1 |
| 36 | Rod Compressor | 11030040 | — | 1 |
| 37 | Compressor Holder | 11030041 | — | 1 |
| 38 | Hook Holder | 11030042 | — | 1 |
| 39 | Large Feeler Probe | 11030043 | — | 1 |
Frequently Asked Questions
What is the primary application of the Zipper 5.5 Instrument Set?
The Zipper 5.5 Instrument Set is engineered specifically for posterior thoracolumbar pedicle screw fixation procedures. It contains specialized tools for site preparation, pedicle tapping, screw insertion, and precise rod contouring.
Which spinal rod diameters are supported by this instrument system?
As indicated by the 5.5 designation, the set is optimized for standard Ø5.5mm spinal stabilization rods, providing compatible grippers, in-situ benders, compressors, and trials.
What tap sizes are included in the standard Zipper 5.5 configuration?
The set includes four standard surgical tap diameters: Ф4.5, Ф5.5, Ф6.0, and Ф6.5, accommodating diverse patient anatomies and screw selections.
Are both multi-axial and mono-axial screwdrivers included?
Yes, the set includes two Multi-Angle Screwdrivers (11030028) and two Mono-Angle Screwdrivers (11030029) to ensure full operational flexibility during spinal construct assembly.
What sterilization methods are recommended for these surgical instruments?
All components are manufactured from medical-grade surgical stainless steel and titanium alloys, compatible with standard hospital autoclave sterilization cycles (pre-vacuum steam sterilization) in compliance with ISO guidelines.
How do the in-situ rod benders facilitate spinal correction?
The set features paired left and right in-situ rod benders that enable the surgeon to fine-tune spinal sagittal or coronal alignment directly within the surgical field after rod placement.
